Excellence in Marine Cable Manufacturing

Marine Cables

Kingfisher Equipment Trading is your trusted energy provider who offers best quality shipboard and offshore cables that range in all sizes. The company continues to prove its excellence in marine electronic solutions by exceeding client’s expectations in meeting quality and on- time delivery standards.

Kingfisher cables product range is in compliance with the national and international standards. Subsequently, our cables have type approval certificates from recognized international marine classification bodies that include TL, BV, LR, GL, DNV, ABS, RMRS, RINA and NK. Kingfisher has a universal presence in the energy and telecommunication arena for which our brand of cables had been installed on vessels locally and internationally.

Shipboard Cables
Marine & Offshore Cables

Write one or two paragraphs describing your product or services.

Cable Properties of our Shipboard cables

Bending Radius	: 6 X Outer Diameter
Halogen free properties	: IEC 60754- 1 & 2
Low smoke emission	: IEC 61034- 1 & 2
Flame Retardancy	: IEC 60332-3 CAT.A
Class	: 2 or 5

Power & Lighting Cables

HF m	: Halogen Free
HFA m EMC	: Halogen Free Armored Cable
HFA m	: Halogen Free Armored Cable
HFFR m	: Halogen Free Fire Resistant
HFFRA m	: Halogen Free Fire Resistant Armored Cable

Technical Features of Power & Lighting Cables

Rated Voltage	: 0.6/1kV
Test Voltage	: 3.5kV
Temperature Range	: -40 C/ +90 C

Application

Used in ships and sea vehicles for power and lighting applications. Halogen-free, flame retardant and low smoke density type cables.
Telecommunication & Control Cable

HFAT m	: Halogen Free Armored Telecommunication & Control Cable
HFFRAT m	: Halogen Free Fire Resistant Armored Telecommunication & Control Cable
HFAT m (C)	: Halogen Free Armored Collectively Screened Telecommunication & Control Cables
HFAT m (I)	: Halogen Free Armored Individually Screened Telecommunication & Control Cables
HFAT m (I+C)	: Halogen Free Armored Individually and Collectively Screened Telecommunication & Control Cables
HFFRAT m (C)	: Halogen Free Fire Resistant Armored Collectively Screened Telecommunication & Control Cable
HFFRAT m (I)	: Halogen Free Fire Resistant Armored Individually Screened Telecommunication & Control Cables
HFFRAT m (I+C)	: Halogen Free Fire Resistant Armored Individually & Collectively Screened Telecommunication & Control Cables

Technical Features of Telecommunication & Control cables

Rated Voltage	: 250 kV
Test Voltage	: 1.5 kV
Temperature Range	: -40 C/ +90 C

Application

Used in ships and sea vehicles for telecommunication and signal applications. Halogen-free, flame retardant and low smoke density type cables.

Table of Standard Design & Tests

Cable Type	IEC 60092-353	IEC 60092-350	IEC 60031-21	IEC 60092-376
HF m	x	x
HFA m EMC	x	x
HFA	x	x
HFFR m	x	x	x
HFFRA m	x	x	x
HFAT m		x		x
HFFRAT m		x	x	x
HFAT m (C)		x		x
HFAT m (I)		x		x
HFAT m (I+C)		x		x
HFFRAT m (C)		x	x	x
HFFRAT m (I)		x	x	x
HFFRAT m (I+C)		x	x	x

Construction

Conductor
Electrolytic, stranded, annealed bare or tinned copper wire

Insulation
Low smoke, halogen free cross-linked polyolefine (LSX)

Inner Sheath
Halogen-free thermoplastic filler or polyester tape

Outer Sheath
Grey or black colored, halogen-free, low smoke, flame-retardant, polyolefine based thermoplastic compound (TPO)

Technical Features

Halogen free properties	: IEC 60754- 1&2
Low smoke emission	: IEC 61034- 1&2
Flame Retardancy	: IEC 60332-3 CAT.A
Standards of Design & Tests	: IEEE 1580-2001 & IEEE 45-2002 & IEC 60331-21

Construction

Conductor
Electrolytic, stranded, annealed, bare copper wire- Class 2

Insulation
HEPR

Inner Sheath
Rubber covering or polyester tape

Screen
Copper wire braiding

Outer Sheath
Chloroprene rubber resistant to oil, fuel and flame

Standards of Design & Tests
IEC 60332-3 CAT.C
DIN 89160
DIN 89159
DIN 89158

Construction

Conductor
Electrolytic, stranded, annealed, bare or tinned copper wire- Class 2 or 5

Insulation
PVC

Inner Sheath
PVC

Outer Sheath
PVC compound resistant to oil, fuel and flame

Standards of Design & Tests
IEC 60092-353 & IEC 60092-350
VG 88775
VG 88777
VG 88778

Low Voltage Power and Control Cables 0.6/1kv

RFOU	Halogen Free, Flame Retardant, Low Smoke, Mud Resistant
BFOU	Halogen Free, Fire Resistant, Flame Retardant, Low Smoke, Mud Resistant
RU	Halogen Free, Flame Retardant, Low Smoke, optional Mud Resistant
BU	Halogen Free, Fire Resistant, Flame Retardant, Low Smoke, Optional Mud Resistant
RFCU	Halogen Free, Flame Retardant, Low Smoke, optional Mud Resistant (Hard Grade EPR)
BFCU	Halogen Free, Fire Resistant, Flame Retardant, Low Smoke, Optional Mud Resistant (Hard Grade EPR)

Table of Code letter for Cable Construction

Code Letter	Construction	Construction Details
R	Insulation	Ethylene propylene rubber (EPR)
F	Inner Covering	Flame retardant & halogen- free compound
O	Armour	Tinned annealed Copper wire braid
U	Outer Sheath	Flame retardant, halogen- free & mud resistant thermoset compound, SHF MUD
B	Insulation	Mica glass tape + EPR
C	Armour	Galvanized steel wire braid
(I)	Individually Screened	Each pair/tripe are screened by copper backed polyester tape in contact with a stranded tinned copper drain wire and wrapped with polyester tape. Printed numbers on insulated conductors identifies Pairs/triples.
(C)	Collectively Screened	Pairs/triples are laid-up and collectively screened by copper backed polyester tape in contact with a stranded tinned copper drain wire. Printed numbers on insulated conductors identifies Pairs/triples.

Applicable Standards of Our Offshore Cables

IEC 600332-3-22 CAT A: Flame Retardant
IEC 60754- 1 & 2 : Halogen Free Properties
IEC 61034- 1& 2 : Low Smoke Properties

Table of Standard Design & Tests

Cable Type	IEC 60093-353	IEC 60092-376	Fire Resistant IEC 60331
RFOU	x
BFOU	x		x
RU	x
BU	x		x
RFCU	x
BFCU	x		x
RFOU (I)		x
RFOU (C)		x
BFOU (I)		x	x
BFOU (C)		x	x
RU (I)		x
RU (C)		x
BU (I)		x	x
BU (C)		x	x
RFCU (I)	x
RFCU (C)		x
BFCU (I)		x	x
BFCU (C)		x	x
RU (I+C)		x
BU (I+C)		x	x
RFOU VFD	x

Halogen Free, Flame Retardant, Low Smoke, Mud Resistant

RFOU (I)

RFOU (C)

BFOU (I)

BFOU (C)

Halogen Free, Flame Retardant, Low Smoke, Optional Mud Resistant

RU (I)

RU (C)

RFCU (I) (Hard Grade EPR)

RFCU (C) (Hard Grade EPR)

RU (I+C) (Hard Grade EPR)

Halogen Free, Fire Resistant, Flame Retardant, Low Smoke, Optional Mud Resistant

BU (I)

BU (C)

BFCU (I) (Hard Grade EPR)

BFCU (C) (Hard Grade EPR)

BU (I+C) (Hard Grade EPR)

Table of Code letter for Cable Construction

Code Letter	Construction	Construction Details
R	Insulation	Ethylene propylene rubber (EPR)
F	Inner Covering	Flame retardant & halogen- free compound
O	Armour	Tinned annealed Copper wire braid
U	Outer Sheath	Flame retardant, halogen- free & mud resistant thermoset compound, SHF MUD
B	Insulation	Mica glass tape + EPR
C	Armour	Galvanized steel wire braid
(I)	Individually Screened	Each pair/tripe are screened by copper backed polyester tape in contact with a stranded tinned copper drain wire and wrapped with polyester tape. Printed numbers on insulated conductors identifies Pairs/triples.
(C)	Collectively Screened	Pairs/triples are laid-up and collectively screened by copper backed polyester tape in contact with a stranded tinned copper drain wire. Printed numbers on insulated conductors identifies Pairs/triples.

Table of Standard Design & Tests

Cable Type	IEC 60093-353	IEC 60092-376	Fire Resistant IEC 60331
RFOU	x
BFOU	x		x
RU	x
BU	x		x
RFCU	x
BFCU	x		x
RFOU (I)		x
RFOU (C)		x
BFOU (I)		x	x
BFOU (C)		x	x
RU (I)		x
RU (C)		x
BU (I)		x	x
BU (C)		x	x
RFCU (I)	x
RFCU (C)		x
BFCU (I)		x	x
BFCU (C)		x	x
RU (I+C)		x
BU (I+C)		x	x
RFOU VFD	x

Variable Frequency Drive Cable

RFOU VFD 0.6/1 kV: Halogen Free, Flame Retardant, Low Smoke, VFD Type, Optional Mud Resistant (Hard EPR)

Application
For use in variable frequency AC motor drive (VFD) applications.

Applicable standards

IEC 600332-3-22 CAT A    : Flame Retardant
IEC 60754- 1 & 2                : Halogen Free Properties
IEC 61034- 1& 2                 : Low Smoke Properties

Table of Code letter for Cable Construction

Code Letter	Construction	Construction Details
R	Insulation	Ethylene propylene rubber (EPR)
F	Inner Covering	Flame retardant & halogen- free compound
O	Armour	Tinned annealed Copper wire braid
U	Outer Sheath	Flame retardant, halogen- free & mud resistant thermoset compound, SHF MUD
B	Insulation	Mica glass tape + EPR
C	Armour	Galvanized steel wire braid
(I)	Individually Screened	Each pair/tripe are screened by copper backed polyester tape in contact with a stranded tinned copper drain wire and wrapped with polyester tape. Printed numbers on insulated conductors identifies Pairs/triples.
(C)	Collectively Screened	Pairs/triples are laid-up and collectively screened by copper backed polyester tape in contact with a stranded tinned copper drain wire. Printed numbers on insulated conductors identifies Pairs/triples.
